Laerdal Compact Suction Unit (LCSU 4) 300ml – Carry Bag Included

Additional information

Laerdal Compact Suction Unit (LCSU4) with 300ml Canister

Combines rugged design with lightweight portability, an essential tool for every first responder.  When a patient’s airway is obstructed, every second counts.

Built to last, the Laerdal Compact Suction Unit 4 combines rugged design with lightweight portability. High performance and low cost, LCSU 4 is the essential tool for every first responder. No vacuum tube between the canister and the suction pump is necessary - just click-in-place and go. A clean and efficient solution, a used canister can be replaced quickly with a new one when suctioning is completed. The canister is sealed, with an internal filter.

The filter automatically stops suction/flow when the canister is full or the filter becomes saturated if the unit tips onto its side during use. Once wet the filter forms a gel which prevents ingress of fluid into the pump. For further use information please see the current LCSU4 user guide

• AC/DC Adapter Charger with AC Power Cord
• Battery
• Multi-language Directions for Use (19 languages)
• 300ml unit with 300ml disposable canister
• Patient tube 0.9m (3”)
• High density protective carry bag

• 2 Year Warranty (excludes canisters, tubing and battery: Battery 90 days)
• Small and lightweight with one-hand-grip design
• Click-in-place 300ml canister, no vacuum tube needed
• Easily convert to 800ml canister option when extra volume is needed
• Disposable canister systems
• Rechargeable Battery, NiMH 12 volt 1.6 Ah with approximately 45 minutes (free flow) run time
• Internal HEPA-rated bacterial filter for all canisters
• High efficiency filter kit (for 800 ml solution)
• Latex free design
• Big vacuum regulator dial, with “clicking sound”
• LED display for use day or night plus a battery level indicator
• Children vacuum range area (marked in blue) on the control panel
• Arrows pointing the vacuum directions
• Wire stand for stability (for both versions)
• No-tools-necessary field changeable battery

What is the battery life of the Laerdal Compact Suction Unit?

The LCSU 4 operates for approximately 45 minutes on a fully charged battery during free flow conditions. The rechargeable NiMH 12-volt 1.6 Ah battery requires about 5 hours to reach a full charge.

How do I clean and maintain the LCSU 4?

With a disposable canister system, eliminating the need for cleaning the canister after use. Simply dispose of the used canister to prevent cross-contamination. Ensure that all external surfaces of the device are wiped down with a suitable disinfectant, and always have an extra canister available for immediate replacement.

Is the LCSU 4 suitable for pediatric patients?

Yes, the LCSU 4 is designed with a vacuum range adjustable from 50 to over 550 mmHg (6.7 to 73.3 kPa), allowing appropriate suction levels for pediatric patients. The control panel includes a marked area indicating reduced suction levels suitable for infants and small children.

Product Specification:

• High flow / High vacuum
• Air Flow @ Vacuum Inlet: 27 LPM (free flow) typical
• Vacuum - Max.: 550+ mmHg (73.3 kPA)
• Vacuum - Range: 50 - 550+ mmHg (6.7 - 73.3 kPa)
• 300 ml canister version: 18.5 cm x 26.2 cm x 8.12 cm (7.3" x 10.3" x 3.2")
• 800 ml canister version: 23.6 cm x 19 cm x 23.6 cm (9.3" x 7.5" x 9.3")
